Place of Origin: | CHINA |
---|---|
Brand Name: | OEM ODM |
Certification: | CE LVD EMC |
Model Number: | S2301 |
Minimum Order Quantity: | 100pcs |
Price: | negotiation |
Packaging Details: | I piece in color box,8pcs in innex box,2 innex boxes in 1 out carton |
Delivery Time: | 30 DAYS |
Payment Terms: | T/T |
Supply Ability: | 100000/MONTH |
Material: | OMRON Relay | VOLT: | 16V |
---|---|---|---|
Color: | White | Programmable: | Non Programmable |
Contact Rating: | 8(2)A 230VAC Max | POWER: | 2*AAA Size Battery |
High Light: | underfloor heating wireless thermostat,underfloor heating programmable thermostat |
Model No.: |
S2301 |
Switchable Voltage: |
24 V AC / DC,…250 V AC; 50 Hz |
Switchable Current: |
6 A (2 A inductive load) |
Programmability: |
Non-Programmable |
Temperature Range (°C): |
0°C-40°C in 0.1°C |
Control Temp.Range (°C): |
5°C-35°C in 0.5°C |
Temp.Meas.Accuracy: |
±1°C (at 20°C) |
Defrosting Temperature: |
+7°C |
Power Method: |
2 x AAA 1.5V Lithium batteries |
Dimensions: |
118 x 80 x 26 mm |
Applications:
1. HVAC System
2. Building ventilation systems
3. Industry ventilation systems
4. Airport,train station,shopping mall, office, classroom and other public places for air quality indication heat/cool
5. Lab.wrehouse and other places to detect CO2+TEMP.+RH%
6. All other ventilation systems
Model No.: |
S2301 |
Switchable Voltage: |
24 V AC / DC,…250 V AC; 50 Hz |
Switchable Current: |
6 A (2 A inductive load) |
Programmability: |
Non-Programmable |
Temperature Range (°C): |
0°C-40°C in 0.1°C |
Control Temp.Range (°C): |
5°C-35°C in 0.5°C |
Temp.Meas.Accuracy: |
±1°C (at 20°C) |
Defrosting Temperature: |
+7°C |
Power Method: |
2 x AAA 1.5V Lithium batteries |
Dimensions: |
118 x 80 x 26 mm |
