| Place of Origin: | GuangDong |
|---|---|
| Brand Name: | OCSTAT |
| Certification: | CE,ROHS |
| Model Number: | S2402 |
| Minimum Order Quantity: | 1pcs |
| Price: | US$13.2-13.5 |
| Packaging Details: | Standard exporting package |
| Delivery Time: | 7-50days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000pcs/mouth |
| Type: | Floor Heating Parts, Floor Heating Systems, Floor Heating Thermostats, Bat-low Indicator, HVAC Systems | Color: | White |
|---|---|---|---|
| Floor Heating Part Type: | Floor Heating Thermostats, Floor Heating Cables, Floor Heating Panels, Under Flooring Heating System | Application: | Underfloor Heating System, Water Heating/Electric Heating System/Boiler, Indoor Underfloor Heating, Electric Underfloor Heating System.Radiant Heating Room Thermostat, Water Heating System |
| Highlight: | HVAC Systems Wired Room Thermostat,7 Day Programmable Wired Room Thermostat,6 Time Wired Room Thermostat |
||
Specification
1.Programmability: Non-programmable
2.Display Temperature Range:0°C~40°C (in 0.1°C increments)
3.Adjustable Temperature Range:5°C~35°C (in 0.5°C increments)
4.Temperature measurement accuracy: ±1°C (at 20°C)
5.Power source: TX: 2x AAA 1.5V Alkaline Battery
6.Load Rating: 6(2)A, 230V
7.Low Battery Indicator: Display ““ when battery is less than 2.7V
8.Standby current:25uA, Lighting current ≤5.5mA
9. Dimensions: 120 x 77 x 28 mm
LCD Display
Backlight
The backlight will be ON by turn the dial and OFF if no any operation for 15 seconds.
Manual Setting
1. Turn the dial in clockwise to increase the temperature, and then press the dial to confirm or wait for 5 seconds to automatically confirm.
2. Turn the dial in anti-clockwise to reduce the temperature, and then press the dial to confirm or wait for 5 seconds to automatically confirm.
