Home ProductsNon Programmable Thermostat

2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

Certification
Good quality Wired Room Thermostat for sales
Good quality Wired Room Thermostat for sales
Stable Quality Excellent Service With Competitive Price Provided

—— Ion

I'm Online Chat Now

2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

China 2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage supplier
2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage supplier 2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage supplier

Large Image :  2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

Product Details:

Place of Origin: Guangdong,China
Brand Name: OCSTAT
Certification: CE,R&TTE,FCC,UL,etc
Model Number: STN701

Payment & Shipping Terms:

Minimum Order Quantity: 500piece
Price: 1-16USD
Packaging Details: one piece in one giftbox
Delivery Time: 50-60days for bulk order,1-7days for sample order
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 100000piece per month
Contact Now
Detailed Product Description
Type: HVAC Systems Usage: Household,Gas Boiler/Water Heating System,indoor&outdoor
Theory: Temperature Controller Color: White
Application: Hotel,indoor,Heat Pump Temp. Range: 44℉ To 90℉
Backlight: Blue Program: Non-programmable
Feature: Energy Saving Material: Flame Retardance ABS+PC
Origin: China Logo: OEM Accept



OCSTAT LCD Digital Temperature Controller STN701 Single Stage 24V Electronic Thermostat



2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

Model: STN701



Display Temperature Range 41ºF to 95ºF (5ºC to 35ºC)
Set Point Range 44ºF to 90ºF (7ºC to 32ºC)
Load Rating 1.0Amp per terminal, 1.5Amp maximum all terminals combined
Display Accuracy ±1ºF(under 68ºF)
Power Source 24 VAC(18 to 30 VAC), 50/60 Hz for hard wire (common wire)
Power Supply 2*AAA 1.5V Alkaline batteries power
Low Battery Indicator Under 2.45V (without 24V power supply)
Backlight Blue, light on for 15 seconds
Dimensions of thermostat W120 x H115 x D24mm



Specification:

- Single stage
- 1 heat,1 cool
- Non-programmable
- 4 sq. inch display
- Blue backlight
- Easy access battery compatment
- Electric or gas configurable
- Separae B&O terminal
- Separate heating and cooling swing(cycle rate)adjustments
- Roomtemperatur calibration adjustment
- 5minute compressor delay protection(slectable on or off)
- Easy wire color coded terminal blocks
- Universal sub-base
- Mounts on wall or junction box
- Battery or 24V power



2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

What we are manufacturing?

1>Programmable/Non-programmable thermostat
2>
Wireless RF/Wired thermostat
3>Touch Screen/Dail/Push Button thermostat
4>Timer/Programmable/Humidity thermostat
5>Pipe/Cylinder Control
6>Ventilation Control
7>Underfloor Heating Control
8>Heating System Control Center
9>Provide OEM/ODM service to worldwide customer, including manufacturing, design,engineering and tooling.





Packaging Details:
1.Inner package:Chinese/English/neutral package,special requirements based on clients.
2.Outer package:standard exporting package,special requirements based on clients.
3.One pcs per box.
Delivery Details:
1.7-50 days,according to the quantity and our stock.
2.usually by express,such as TNT,DHL,UPS,EMS,PEDEX,etc.Will take about a week from sending to get to your address.
3.Warranty:We are responsible for any defects in quality or workmanship within one year and repair them free of charge within one year.



2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage
Our Services:

1. Delivery time is 7 days for sample order and 40 working days for bulk order
2. Strong production capacity and strict quality control system
3. Your inquiry and problems related to our products or prices will be replied in 24 hours
4. Well-trained and experienced staffs to answer all your inquires
5. After-sale tracking service for all of our clients
6. OEM is available,small quantities, mixed bulk orders are also welcome
7. Payment: L/C, D/A, D/P, T/T, Paypal , Western Union, Money Gram
8. Delivery way: UPS, DHL, TNT, FEDEX, EMS, CHINA POST


2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage

2019 OCSTAT 24V Non Programmable Thermostat LCD Digital Temperature Controller 1 Stage
